Controls

Automation - a true system
Packaging machines, robotics, and handling systems are often particularly challenging from the standpoint of automation technology. They require a powerful and homogeneous system capable of controlling coordinated movements along several axes. The system must also be able to assume the control function of a linear process.

For these automation tasks, you will find the controllers you need for controller-based and drive-based automation.

Call Walker Industrial today for Lenze product selection and availability. Call or email us today!
Controller 3200 C The compact heart of your automation systems. The Controller 3200 C with Atom processor offers everything that an automation specialist desires from a strong partner: a compact and especially robust design, large power reserves and a comprehensive set of features.
  • Logic (PLC), motion and visualization in a single device
  • Easy engineering with remote data storage
  • High-precision control for optimum production results
  • Easy mounting onto a DIN rail in the control cabinet
  • I/O system 1000 can be directly connected as local I/Os
  • Top performance and maintenance free in the smallest of spaces without forced cooling and other moving components
  • Prepared for the future thanks to compliance with industrial standards
  • IEC 61131-3, PLCopen, PLC Designer based on CoDeSys 3
  • Industrial communication: EtherCAT on board and Ethernet switch integrated
  • Intel Atom® processor
Controller c300 The slimline solution for the control cabinet. Based on the 3200 C, the c300 fits seamlessly into Lenze's platform which is built on a consistently modern system architecture. The benefits: within the Controller-based Automation system, the precisely tailored Controller c300 takes responsibility for all of your control tasks. It focusses primarily on basic control (PLC) and motion tasks. Space-saving and intelligent at the same time.
  • Small control system with I/O modules which can be connected in series and integrated master interfaces for EtherCAT and CanOpen
  • Easy standard set-up and data backup via USB flash drive
  • Can be extended with communication interfaces (PROFIBUS slave, PROFINET device)
  • Future-proof due to compliance with industrial standards
  • High system-availability
  • Integrated UPS solution
  • Easy device replacement thanks to replaceable memory card
  • No need for maintenance thanks to battery-free and fanless design
Controller p300 Visualization that's a touch smaller. Based on the Panel Controller p500, the new p300 fits seamlessly into Lenze's platform which is built on a consistently modern system architecture. It combines logic (PLC) and visualization in a compact device and is ideally suited to machine applications which only require a low processing power. With the same system properties as its older brother, its strength lies in its visualization capabilities when used as an HMI. By extending the Controller portfolio with the p300, Lenze has opened up new possibilities within the system. Isn't it great when engineering is so easy?!
  • Robust industry-compliant Panel Controller available in sizes 10.9 cm (4.3"), 17.8 cm (7") and 26.4 cm (10.4")
  • For basic to complex control and visualization tasks
  • Uniform engineering in all phases of the customer's machine development process
  • High degree of system availability
  • Integrated UPS solution
  • Simple device replacement via replaceable memory card
  • No maintenance required thanks to battery-free and fanless design
Controller p500 It's easy with everything on the screen. Lenze has taken yet another step towards creating an easier future with the p500 – a perfect combination of maintenance-free panel-mounted controller, logic (PLC), motion and visualization in a single device. It is ideally suited for use as a control and visualization system within controller-based automation systems suiting applications with central motion control or as a visualization device within a drive-based automation system.
  • Logic (PLC), motion and visualization in a single device
  • Machine-oriented and high-precision control for optimum manufacturing results
  • Top performance and maintenance free in the smallest of spaces without forced cooling and other moving components
  • Prepared for the future thanks to compliance with industrial standards
  • IEC 61131-3, PLCopen, PLC Designer based on CoDeSys 3
  • Industrial communication: EtherCAT on board and Ethernet switch integrated
I/O System 1000 Provides top performance in the tightest of spaces. At the very first glance, the I/O 1000 range impresses with the narrow design of its I/O modules, which can take up to 8 connections. They only require 0.5 in (12.5 mm) of space on conventional DIN rails.
  • 0.5 in (12.5 mm) narrow I/O modules with 8 connection points
  • Permanent wiring thanks to the two-part concept
  • Base module and electronic module
  • Bus coupler for industrial communication: CANopen, DeviceNet, EtherCAT, Modbus/RS485, PROFIBUS, PROFINET
  • Can be mounted onto the DIN rail without the need for tools
  • Clear labeling concept and diagnostic concept
  • An LED and a labeling field are clearly assigned to each channel
  • 64 modules can be connected in series using a backplane bus
  • Easy to connect thanks to the connection plan on the module
Industrial PC v800-C The powerful v800-Cabinet for integration into the machine housing. Machine visualizations with the industrial PC v800-C can be easily scaled and implemented in a way that is optimal for the machine. The different screen diagonals and processor capacities are tailor-made for the necessary requirements of modern visualization systems, and are suitable for any machine concept. All devices are equipped with the most up-to-date, glove-friendly multi-touch glass sensors, and the operating program can be created intuitively with the engineering software VisiWinNET®.
  • High-resolution displays in 13.3 to 24 in
  • Non-rotating mass storage
  • Fan cooled for maximum power or passively cooled
  • Innovative cooling method and durable fan
  • IP65 protection class front
  • VisiWinNET® for creating intuitive visualizations
Industrial PC v800-P The high-quality solution: v800-Protec. An appealing, elegant device design with an IP65 degree of protection, and a shape that ensures ease of cleaning, results in a product that offers simple elegance with maximum functionality and the best possible platform for demanding user interface concepts. A high degree of standardization guarantees maximum availability and protection of software investments over a long period of time.
  • High resolution full HD displays in 17.3 and 24 in
  • Maintenance-free thanks to no rotary components
  • IPC type with low-power Intel© mobile processors
  • Complies with hygienic design guidelines, no visible screws, and an IP65 degree of protection
  • Individualization via optional switch box
Monitor Panels Provide a perfect overview when operating decentralized IPC solutions. Display unit for remote solutions with Controller 3200 C or Industrial PCs.
  • In two design versions
    • Embedded Line for installation
    • Command station
  • Data transfer via digital DVI video interface
  • Operator terminal with integrated keyboard or touch screen
  • Operator terminal compatible with all Lenze Industrial PCs
Monitor v200-P The modern monitor: v200-Protec. An appealing, elegant device design with an IP65 degree of protection, and an easy-to-clean design, results in sleek elegance with maximum functionality and the best possible platform for demanding user interface concepts. A high degree of standardization guarantees maximum availability and protection of investments over a long period of time.
  • High-resolution full HD displays in 17.3 and 24 in
  • Standard HDMI or DisplayPort connection
  • Optional mounting up to 100 m from control cabinet PC via integrable extender
  • Complies with hygienic design guidelines, with no visible screws, and an IP65 degree of protection
