601-CS-D-P1 - SymCom 3-Phase Ground Fault Monitor
601-CS-D-P1 - SymCom
601-CS-D-P1
This is a family photo and may not be an accurate representation of the product.

Price: $701.83
Returnable: NOT RETURNABLE
Manufacturer SKU: 601-CS-D-P1



Availability: Usually Ships in 3 to 5 Days
Part Number: 601-CS-D-P1
Qty:

Description

601-CS-D-P1 - SymCom 3-Phase Ground Fault Monitor

This product must be used with an external Zero-Sequence CT for proper operation (not included).

The 601-CS-D-P1 Family
3-phase power monitor is a fully programmable electronic power monitor designed to monitor 3-phase systems. The 601-CS-D-P1 has a single relay that can be configured as a general purpose network output or to trip on ground faults. The 601-CS-D-P1 monitors ground fault current, phase currents, phase voltages, power factor and frequency. The RS485MS-2W communications module allows the 601-CS-D-P1 to communicate using the Modbus RTU protocol. The Modbus connection can be used to monitor power parameters, setup the device or control the fault relay. A DeviceNet™ communications I/O module (CIO-601CS-DN-P1) is available as well. This CIO module only works with the 601-CS-D-P1 unit. It is used for sending the information from the 601-CS-D-P1 over a DeviceNet™ network. It also provides I/O capabilities and the ability to set the parameters of the 601-CS-D-P1.

Features:

  • Ground fault warning (enable/delay)
  • Ground fault trip (enable/trip delay)
  • Ground fault motor acceleration (enable/trip delay)
  • Modbus communications watchdog

Auxiliary Products:

  • CIO-601CS-DN-P1
pdfDownload the The SymCom Product Line catalog in *.pdf format
pdfDownload the SymCom Overview brochure in *.pdf format
pdfDownload the Ground Fault Monitor datasheet in *.pdf format
