1SVR550805R9300 - ABB 1SVR550805R9300, RELAYCM-MSE_ THERM. MOTOR PRO

1SVR550805R9300 - ABB
1SVR550805R9300

Price: $66.14
Returnable: NOT RETURNABLE
Manufacturer SKU: 1SVR550805R9300
Manufacturer ID: 662019039152



Availability: Usually Ships in 3 to 5 Days
Part Number: 1SVR550805R9300
Qty:

Description

1SVR550805R9300 - ABB 1SVR550805R9300, RELAYCM-MSE_ THERM. MOTOR PRO

The motor load monitoring relay monitors the load states of single-phase and three-phase asynchronous motors. Compared with other conventional measuring principles (e.g. pressure transducers, current measurement), the cos monitoring is a more precise and economical alternative. It measures the voltage of all three phases, the current of one phase and calculates the phase angle (cos) between them to evaluate the status of the motor.

Main benefits

  • Down time reduction
  • Easy commissioning
  • Easy maintenance

Main features

  • Under- and overload monitoring cos in one unit
  • Adjustable start-up delay 0.3-30 s
  • Direct measurement of currents up to 20 A
  • Adjustable response time delay 0.2-2 s
  • Single-phase or three-phase monitoring
  • 2 x 1 c/o contact, closed-circuit principle
pdfDownload the Electronic Products and Relays catalog in *.pdf format
