TM3A605 - Eagle Signal Electric repeat cycle cam timer; Surface mtg.; 120VAC/60Hz; 60 sec.

TM3A605 - Eagle Signal Controls
TM3A605

Price: $353.00
Returnable: NOT RETURNABLE
Manufacturer SKU: TM3A605



Availability: Usually Ships in 3 to 5 Days
Part Number: TM3A605
Qty:

Description

This part is Non-Cancelable and Non-Returnable once the production order is placed with the factory.

TM3A605 - Eagle Signal Electric repeat cycle cam timer; Surface mtg.; 120VAC/60Hz; 60 sec.

The TM series TIME/MODULE consists of a series of modules, each interlocking with the other and keyed so that they can be assembled only one way. Choosing the correct combination of modules will solve virtually all repeating time control problems. Standard units are available with one through ten switches. There are six modules available, each distinctive in its separate function. They include a motor module with clutch, dial and knob module, a 10-1 reduction module, and three different switch modules as follows: one rise and drop tab with latch actuator (standard), two rise tabs with cam follower, and two 50-50 cam segments with cam follower.
