RSCDN-20A - IDEC Solid State Relay 20A Load, 4-32VDC Input

RSCDN-20A - IDEC
RSCDN-20A

Price: $46.95
Manufacturer SKU: RSCDN-20A



Availability: Usually Ships in 3 to 5 Business Days
Part Number: RSCDN-20A
Qty:

Description Technical Specs

RSCDN-20A - IDEC Solid State Relay 20A Load, 4-32VDC Input

The RSC Series Family
RSC relays have technology to dissipate the heat away from main switching components, making them a great buy. Other relays may require you to add your own heat sink or deal with a burned out product, but the new RSC relays from IDEC have a built-in heat sink making them easy to install and get running. The heat sink, along with an epoxy-free design, eliminates the need to de-rate your relay and also increases its life expectancy. And an LED status indicator makes sure you can see it working.

The slim design of the RSC relays provides a compact unit for DIN Rail or panel mounting without wasting space. 20A and 30A current ranges are 22.5mm, while the relays with 45A current are 45mm. All RSC relays are UL recognized, CE marked, as well as being lead-free and RoHS compliant.

Key Features
  • Choice of 20A, 30A and 45A models
  • Slim design allows for compact DIN rail or panel mounting
  • Built-in heat sink
  • Epoxy-free design and improved thermal impedance
  • LED indicator
  • Finger-safe terminals
  • Zero voltage switching
  • UL recognized, CSA Certifi ed, TUV Approved, CE Marked
  • Lead-free and RoHS compliant
  • EMC (Level 3) & IEC 62314 compliant
pdfDownload the RSC Series Solid State Relays catalog in *.pdf format
pdfDownload the Solid State Relays with Built-in Heat Sink - RSC datasheet in *.pdf format
