These Gearboxes have superior accuracy of less than 1 arc-min and as SHORT as 70mm (Flange to Flange), and the Apex AD fits into the smallest spaces
- Output torque
T2N : 14 Nm - 2000 Nm
- Ratios
1-stage : 4 / 5 / 7 / 10
2-stage : 20/25/35/40/50/70/100/16/21/31/61/91
- Low backlash
1-stage : ≤1 arcmin / ≤3 arcmin / ≤5 arcmin
2-stage : ≤3 arcmin / ≤5 arcmin / ≤7 arcmin
- high efficiency
1-stage : ≧ 97%
2-stage : ≧ 94%
- Easy mount
- Low Noise
- Compact structure
Click to view the AD Series Dimensions in *.pdf format
Click to view the AD Series Specifications in *.pdf format
|
