High precision rotary flange - shaft input, high torsional rigidity high output moment load capacity, Tapped Rotary Flange ISO 9409 Round Thru Hole Flange Machine Mounting Shaft Input

• Output torque
  T2N : 14 Nm - 2000 Nm

• Ratios
  1-stage : 4 / 5 / 7 / 10
  2-stage : 16/21/31/61/91

• Low backlash
  1-stage : ≤1 arcmin / ≤3 arcmin / ≤5 arcmin
  2-stage : ≤3 arcmin / ≤5 arcmin / ≤7 arcmin

• high efficiency
  1-stage : ≧ 97%
  2-stage : ≧ 94%

• Easy mount

• Low Noise

• Compact structure

Click to view the ADS Series Dimensions in *.pdf format

Click to view the ADS Series Specifications in *.pdf format
