Fits Industry Standard 2.5", 58mm and 85mm Flanges Shaft Sizes 1/4"-3/8" [10mm-18mm] Directly Replaces Standard Models Up to 27 Bit Resolution Moisture-Proof, Shock Resistant Magnetic Sensor Singleturn or Multiturn IP65 Rating Bearings 20X Larger Than Standard Encoder! No Batteries or Gears! -40° to 85°C Operation 3 Year No-Hassle Warranty

Click to view the AV30 Series Datasheet in *.pdf format

AV30 shafted magnetic absolute rotary encoders offer a completely new level of durability, never seen before in absolute encoders. Yet the AV30 encoder will fit existing flanges and mounts, enabling easy upgrades from low durability encoders. Also available: hollow shaft model (HS40), absolute+incremental combo units (HS45, AV45) as well as optical models (AV6A, HS6A) for ultra-precision applications.

The AV30 features massive bearings with over 10X the load rating of the competition. Industry-leading seal systems stay sealed to keep contaminants out, through temperature cycling and liquid sprays. Moreover, the magnetic sensor can see through oil, dust and dirt that disable ordinary optical absolute encoders.

By utilizing Wiegand wire energy harvesting technology combined with magnetic sensors, Avtron has created an absolute encoder design which requires no batteries, long-term capacitors, glass disks, or gears!

The AV30 features a broad range of industry standard communication protocols: from analog outputs to CANopen, Profibus, J1939, and SSI, you will find the communication protocol you need.

Stop suffering costly downtime due to absolute encoder failures--upgrade to AV30 today!

Specs:
Operating Power:
