Direct Replacement for All 5BC42, 5BC46, 5BC66, and 5PY Tachogenerators Severe Mill Duty Fits Existing Bolt Patterns No Drive Configuration Changes Required No Brushes, No Maintenance Better Speed Regulation Self-Diagnostic LED and Alarm Output -40C* to +120C* Operation 1 Year No-Hassle Warranty

Click to view the Brushless Tachometer Datasheet in *.pdf format

Replaces GE 5BC42/46/66 and 5PY Analog Tachogenerators, NEMA 56C Face & Foot Mount.

The Avtron Brushless Upgrade Package with K661 and AV485 encoders replaces old, obsolete GE 5BC42, 5BC46 & 5BC66 analog tachogenerator models. It fits existing bolt patterns: both foot mount and existing motor flanges (NEMA 56C style). Other Avtron model encoders (AV850) are available to eliminate moving, wearing parts and motor flanges completely!

Avtron also offers the AV44 encoder for direct drop-in replacement of 5PY analog tachometers.

Using the Avtron update package, you will improve the output and speed control accuracy of your machine, while eliminating costly downtime.

Unlike low-quality converters, the Avtron solution is extremely linear and accurate, with no “gearshift” behaviors that can damage your product quality. The output is repeatable to 0.002%! The K661 offers 50V/1000RPM, 100V/1000RPM and 200V/1000RPM selections to replace all common tach styles.

The brushless upgrade package is simple to install: mount the K661 converter in your drive cabinet, route a new encoder-to-drive shielded twisted pair cable, and mount the Avtron AV485 encoder. There are no changes required to your existing drives.

Keep your analog drives working for years to come, improve reliability, and increase your machine output. Select the Avtron Brushless Upgrade Package today!
Operating Power: 110VAC, 0.25A

• K661: 0°C to -60°C (for cabinet mount)
• AV485: -40°C* to +120°C* (for machine mount)
• AV850: -40°C to +100°C (for machine mount)
