Digistart D2


Sort By:
1


1
Applications for digital soft starter Digistart D2

Digistart D2 is ideal for a wide range of applications, including:

  • Conveyors
  • Fans
  • Pumps (Centrifugal & Submersible)

Digistart D2- Compact Digital Soft Starter with Motor Protection

The Digistart D2 is among the most compact constant current/current ramp soft starters available. The built in bypass contactor eliminates heat dissipation and energy losses by bridging out the power devices once the motor is at full speed. This eradicates the need for external bypass contactors saving panel space, simplifying installation and allowing the use of non-ventilated enclosures.

Digistart D2 units can be mounted side-by-side and are DIN rail mountable up to 60 A. This is ideal where multiple soft starters are required such as in motor control centers.

Benefits:
  • Motor Current Protection
  • Universal Input Voltage (200-575 VAC)
  • Compact Design, Smallest Footprint
  • Built-in Bypass Contactor
  • DIN Rail Mounting Up To 60 A
  • 2 Wire or 3 Wire Start Stop Control Circuit
  • Modbus, Profibus and DeviceNet Options
  • Remote Operator Option
  • Constant Current Start
  • Current Ramp Start
  • Equi-Vecâ„¢ Balanced Vector Control Technology
