Unimotor HD AC Servo Motors


Sort By:
1 2 3 ... 10
055UDC300BAEGA063110 - Control Techniques 055UDC300BAEGA063110 - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 55mm Frame, 12.6lb-in (1.42Nm), 0.96A, 3000rpm, Inductive EnDat multi-turn, no brake, size 1.0 power, 90 degree rot. conns, Key installed, std inertia, 63mm BCD, 11mm Usually Ships in 3 to 5 Business Days
Price: $2,032.00
060EDB600SAEGC - Control Techniques 060EDB600SAEGC - Control Techniques Servo Motors Unimotor hd Servo Motor, 230Vac, 60mm Frame, 11.3lb-in (1.28Nm), 2.72A, 6000rpm, Ind EnDat multi-turn, Single cable, Key installed, std inertia Usually Ships in 3 to 5 Business Days
Price: $1,128.00
060UDB600TACTA - Control Techniques 060UDB600TACTA - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 60mm Frame, 11.3lb-in (1.28Nm), 1.77A, 6000rpm, Inc. Enc. 4096ppr, Ytec conn, Key installed, std inertia Usually Ships in 3 to 5 Business Days
Price: $860.00
067EDA300BACTA - Control Techniques 067EDA300BACTA - Control Techniques Servo Motors Unimotor hd Servo Motor, 230Vac, 67mm Frame, 12.1lb-in (1.37Nm), 1.53A, 3000rpm, Inc. Enc. 4096ppr, size 1.0 power, 90° rot. conns, Key installed, std inertia, 75mm BCD, 14mm shaft dia. Usually Ships in 3 to 5 Business Days
Price: $1,048.00
067EDA306BACTA - Control Techniques 067EDA306BACTA - Control Techniques Servo Motors Unimotor hd Servo Motor, 230Vac, 67mm Frame, 12.1lb-in (1.37Nm), 1.53A, 3000rpm, Inc. Enc. 4096ppr, 24Vdc holding brake, size 1.0 power, 90-degree rot. conns, Key installed, std inertia, 75mm BCD, 14mm shaf Usually Ships in 3 to 5 Business Days
Price: $1,420.00
067UDC300BAEGA - Control Techniques 067UDC300BAEGA - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 67mm Frame, 30.4lb-in (3.43Nm), 2.26A, 3000rpm, Abs.Enc. Ind. EnDat Multi-turn, size 1.0 power, 90° rot. conns, Key installed, std inertia Usually Ships in 3 to 5 Business Days
Price: $1,512.00
089UDB306BARAA - Control Techniques 089UDB306BARAA - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 89mm Frame, 42.1lb-in (4.8Nm), 5.72A, 3000rpm, 3000rpm, Abs. Enc. Hiperface Multi-turn, 24Vdc holding brake, size 1.0 power, 90° rot. conns, Key installed, std inertia Usually Ships in 3 to 5 Business Days
Price: $2,624.00
089UDB600BBECC - Control Techniques 089UDB600BBECC - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 89mm Frame, 32.6lb-in (3.7Nm), 6.69A, 6000rpm, Ind EnDat SinCos multi-turn, size 1.0 power, 90° rot. conns, Plain shaft, std inertia Usually Ships in 3 to 5 Business Days
Price: $1,808.00
089UDC606BACAA - Control Techniques 089UDC606BACAA - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 89mm Frame, 42.9lb-in (4.9Nm), 9.70A, 6000rpm, 90° conns, Inc. Enc. 4096ppr, 24Vdc holding brake,std. inertia Usually Ships in 3 to 5 Business Days
Price: $2,148.00
115UDC306DBFFC - Control Techniques 115UDC306DBFFC - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 115mm Frame, 91.1lb-in (10.3Nm), 8.92A, 3000rpm, Single Hybrid Connector, inductive single-turn absolute, EnDat, KTY84, 24Vdc holding brake Usually Ships in 3 to 5 Business Days
Price: $2,636.00
115UDD206BACTA - Control Techniques 115UDD206BACTA - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 115mm Frame, 135.3lb-in (15.3Nm), 7.64A, 2000rpm, Inc. Enc. 4096ppr, 24Vdc holding brake, size 1.0 power, 90° rot. conns, Key installed, std inertia Usually Ships in 3 to 5 Business Days
Price: $2,632.00
115UDD300BAECC - Control Techniques 115UDD300BAECC - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 115mm Frame, 118.0lb-in (13.3Nm), 11.56A, 3000rpm, Inductive EnDat SinCos multi-turn, size 1.0 power, 90° rot. conns, Key installed, std inertia Usually Ships in 3 to 5 Business Days
Price: $2,312.00
142UDC150BAHBA - Control Techniques 142UDC150BAHBA - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 142mm Frame, 163.5lb-in (18.5Nm), 6.46A, 1500rpm, Abs. Enc. EnDat Single-turn, size 1.0 power, 90° rot. conns, Key installed, std inertia Usually Ships in 3 to 5 Business Days
Price: $3,872.00
142UDC200BACAA - Control Techniques 142UDC200BACAA - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 142mm Frame, 157.1lb-in (17.7Nm), 8.65A, 2000rpm, 90° conns, Inc. Enc. 4096ppr, std inertia Usually Ships in 3 to 5 Business Days
Price: $3,080.00
190UDC200JFCAA - Control Techniques 190UDC200JFCAA - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 190mm Frame, 376.2lb-in (42.5Nm), 21.7A, 2000rpm, Inc. Enc. 4096ppr, size 1.5 power, 90° rot. conns, Key and half key supplied,, std inertia Usually Ships in 3 to 5 Business Days
Price: $4,204.00
190UDC300JACTA - Control Techniques 190UDC300JACTA - Control Techniques Servo Motors Unimotor hd Servo Motor, 460Vac, 190mm Frame, 290.3lb-in (32.8Nm), 29.9A, 3000rpm, Inc. Enc. 4096ppr, no brake, size 1.5 power, 90° rot. conns, Key installed, std inertia Usually Ships in 3 to 5 Business Days
Price: $4,204.00
055EDA300BACRA063110 - Control Techniques Emerson - 055EDA300BACRA063110 - Control Techniques Servo Motors - Unimotor HD Servo Motor, 230VAC, 55mm Frame, 6.37 lb-in Cont. Stall Torque, 3000RPM Max Speed, Connectorized, Incremental Encoder, Braked Usually Ships in 1 to 2 weeks
Price: $1,104.00
055EDA305BACRA063110 - Control Techniques Emerson - 055EDA305BACRA063110 - Control Techniques Servo Motors - Unimotor HD Servo Motor, 230VAC, 55mm Frame, 6,2lb-in (0.7Nm), 0.97A, 3krpm, Inc. Enc. 4096ppr,24VDC holding brake, size 1.0 power, 90rot. conns, Key installed, std inertia, 63mm B Usually Ships in 1 to 2 weeks
Price: $1,488.00
055EDB300BACRA063110 - Control Techniques Emerson - 055EDB300BACRA063110 - Control Techniques Servo Motors - Unimotor HD Servo Motor, 230VAC, 55mm Frame, 9.3lb-in (1.05Nm), 1.36A, 3krpm, Inc. Enc. 4096ppr,no brake, size 1.0 power, 90rot. conns, Key installed, std inertia, 63mm BCD,11mm sh Usually Ships in 1 to 2 weeks
Price: $1,164.00
055EDB305BACRA063110 - Control Techniques Emerson - 055EDB305BACRA063110 - Control Techniques Servo Motors - Unimotor HD Servo Motor, 230VAC, 55mm Frame, 9.3lb-in (1.05Nm), 1.36A, 3krpm, Inc. Enc. 4096ppr,24VDC holding brake, size 1.0 power, 90rot. conns, Key installed, std inertia, 63mm Usually Ships in 1 to 2 weeks
Price: $1,548.00
055UDA300BACRA063110 - Control Techniques Emerson - 055UDA300BACRA063110 - Control Techniques Servo Motors - Unimotor HD Servo Motor, 460VAC, 55mm Frame, 6.2lb-in (0.7Nm), 0.97A, 3krpm, Inc. Enc. 4096ppr,no brake, size 1.0 power, 90rot. conns, Key installed, std inertia, 63mm BCD,11mm sha Usually Ships in 1 to 2 weeks
Price: $1,104.00
055UDA305BACRA063110 - Control Techniques Emerson - 055UDA305BACRA063110 - Control Techniques Servo Motors - Unimotor HD Servo Motor, 460VAC, 55mm Frame, 6.2lb-in (0.7Nm), 0.97A, 3krpm, Inc. Enc. 4096ppr,24VDC holding brake, size 1.0 power, 90rot. conns, Key installed, std inertia, 63mm B Usually Ships in 1 to 2 weeks
Price: $1,488.00
055UDB300BACRA063110 - Control Techniques Emerson - 055UDB300BACRA063110 - Control Techniques Servo Motors - Unimotor HD Servo Motor, 460VAC, 55mm Frame, 9.3lb-in (1.05Nm), 0.79A, 3krpm, Inc. Enc. 4096ppr,no brake, size 1.0 power, 90rot. conns, Key installed, std inertia, 63mm BCD,11mm sh Usually Ships in 1 to 2 weeks
Price: $1,164.00
055UDB305BACRA063110 - Control Techniques Emerson - 055UDB305BACRA063110 - Control Techniques Servo Motors - Unimotor HD Servo Motor, 460VAC, 55mm Frame, 9.3lb-in (1.05Nm), 0.79A, 3krpm, Inc. Enc. 4096ppr,24VDC holding brake, size 1.0 power, 90rot. conns, Key installed, std inertia, 63mm Usually Ships in 1 to 2 weeks
Price: $1,548.00
055UDC305BACRA063110 - Control Techniques Emerson - 055UDC305BACRA063110 - Control Techniques Servo Motors - Unimotor HD Servo Motor, 460VAC, 55mm Frame, 13.1lb-in (1.48Nm), 1.0A, 3krpm, Inc. Enc. 4096ppr,24VDC holding brake, size 1.0 power, 90rot. conns, Key installed, std inertia, 63mm Usually Ships in 1 to 2 weeks
Price: $1,772.00
060EDA600BACTA - Control Techniques Emerson - 060EDA600BACTA Control Techniques, Unimotor hd Servo Motor, 230Vac, 60mm Frame, 5.7lb-in (0.64Nm), 1.36A, 6000rpm, Inc. Enc. 4096ppr, Ytec conn, Key installed, std inertia Usually Ships in 1 to 2 weeks
Price: $826.40
060EDA605BACTA - Control Techniques Emerson - 060EDA605BACTA Control Techniques, Unimotor hd Servo Motor, 230Vac, 60mm Frame, 5.7lb-in (0.64Nm), 1.36A, 6000rpm, Inc. Enc. 4096ppr, 24Vdc holding brake, Ytec conn, Key installed, std inertia Usually Ships in 1 to 2 weeks
Price: $1,056.80
060EDB600BACTA - Control Techniques Emerson - 060EDB600BACTA Control Techniques, Unimotor hd Servo Motor, 230Vac, 60mm Frame, 11.3lb-in (1.28Nm), 2.72A, 6000rpm, Inc. Enc. 4096ppr, Ytec conn, Key installed, std inertia Usually Ships in 1 to 2 weeks
Price: $860.00
060EDB605BACTA - Control Techniques Emerson - 060EDB605BACTA Control Techniques, Unimotor hd Servo Motor, 230Vac, 60mm Frame, 11.3lb-in (1.28Nm), 2.72A, 6000rpm, Inc. Enc. 4096ppr, 24Vdc holding brake, Ytec conn, Key installed, std inertia Usually Ships in 1 to 2 weeks
Price: $1,091.20
060EDC600BACTA - Control Techniques Emerson - 060EDC600BACTA Control Techniques, Unimotor hd Servo Motor, 230Vac, 60mm Frame, 17lb-in (1.92Nm), 4.09A, 6000rpm, Inc. Enc. 4096ppr, Ytec conn, Key installed, std inertia Usually Ships in 1 to 2 weeks
Price: $899.20


1 2 3 ... 10
Pulse duty servo motor

6.3 lb-in – 757.6 lb-in (2257 lb-in peak); 0.72 Nm – 85 Nm (255.0 Nm peak)
230 V | 460 V

This high peak torque, low inertia motor range is designed for high dynamic applications requiring hard accelerations and decelerations including:

  • Flying shear
  • Pick and place
  • Cut-to-length

Unimotor hd motors are perfectly matched to Digitax HD servo drives.
