SLM500 StreamLine Modular Multifunctional LED Combination Audible/Visual Signal
|
|
|
|
|
Overview
Model SLM500 is a multifunctional LED beacon and sounder combination developed with a multiple input technology that allows three separate levels of alarm (alert, pre-alarm, alarm) controllable via independent electric contacts. Channel 1 includes a simulated strobe (triple flash) visual signal only. Channel 2 adds an audible tone, selectable from 32 tones via DIP switch, to the simulated strobe effect. Channel 3 includes a steady light and a second, unique tone selectable from 32 different toness, for a total of 64 unique tones. The volume of a selected tone is adjustable (65-105 dBa) for the highest performing tone. Its enclosure is made from a self-extinguishing polycarbonate material with high impact and UV resistance.
- Compatible with 12-24VAC/DC or 120-240VAC*
- PLC compatible with PNP or NPN connections*
- 3 Channels included
1: Visual only
2: Visual + tone 1
3: Visual + tone 2 - 50,000-hour LED
- Five color options: Amber, Blue, Clear, Green and Red
- Seven mounting base options (sold separately)
- Type 3R, IP65 enclosure
- CE Certified
- UL and cUL listed
|
|
|
