The new LM Series laser distance sensor provides precise measurement and reliable detection of difficult targets.
Applications:
- Precise part inspection
- Assembly and accuracy checks
- Dimensional control
- Product position control
- PCB warp inspection
- Correct product placement
- Thickness and height measurement
PRECISE MEASUREMENT: The LM provides reliable quality and process control with 0.004 mm resolution and repeatably measures real world targets with varying colors and reflectivity.
HIGH-SPEED
With response speeds as fast as 0.5 ms, the LM can reliably solve high-speed applications with fast-moving targets.
REAL-WORLD STABILITY
LM sensors feature a thermally stable design that resists temperature changes, as well as enhanced mounting stability, for high accuracy in the toughest environments. The LM has a temperature effect of +/-0.008 mm/°C. This is imperative for high precision applications since even a few degrees of temperature change can cause other sensors' measurement error to double
Download the LM Series Laser Sensor Manual in *.pdf format
Download the LM Series Refrence Guide in *.pdf format
Download the LM Series Quick Start Guide in *.pdf format
|
