VS8 Series Miniature Photoelectric Sensors


Key Benefits:

· Versatility: Sensors in the VS8 series have a space-saving form factor (21.1 mm x 14.6 mm x 8 mm). They are available in laser and LED models and in four different sensing modes. Users can match the sensing technology to the application without altering equipment design.

· Rapid Integration: Industry standard side mounting holes with 15 mm spacing simplify installation on new or existing equipment. The dovetail mounting option allows ±10° tip/pivot adjustments for quick, precise alignment. High-visibility status LEDs, electronic push-button and remote input teach make it easy to program the sensors.

· Precision: Models with a red laser sensing beam have a bright, precise spot for detecting small objects and multicolored targets. Red laser models with adjustable or fixed-field background suppression can detect an object with a diameter of 0.5 mm at a distance of 70 mm.

· Reliable Detection of Challenging Targets: Models with a blue LED sensing beam reliably detect difficult targets with dark or reflective surfaces and transparent objects, like foils, thin films, glass, and plastic. These models do not require a reflector, ideal for use in space-constrained applications.
